Air Compressor Filter
| Model | Connection | Air Flow Rate | Dimensions | Filter Element Model |
| HOS | mm | Nm³/min | mm | |
| 015 | 3/4 " | 1.5 | 85*85*245 | 015 |
| 024 | 1 1/2 " | 1.5 | 110*110*315 | 024 |
| 035 | 1 1/2 " | 3.5 | 110*110*315 | 035 |
| 060 | 1 1/2 " | 6 | 110*110*450 | 060 |
| 090 | 2 1/2 " (2") | 9 | 140*133*510 | 090 |
| 120 | 2 1/2 " (2") | 12 | 140*133*870 | 120 |
| 150 | 2 1/2 " (2") | 15 | 140*133*870 | 150 |
| 240 | Customized | 24 | 350*133*980 | -44 |
| 360 | Customized | 36 | 420*230*940 | -44 |
| Model | Connection | Air Flow Rate | Dimension | Filter Element Model |
| DM16 bar | mm | Nm³/min | mm | |
| 0100 | 1" (3/4" ) (1/2" ) | 1.2 | 100*85*250 | 0100 |
| 0200 | 1" (3/4" ) (1/2" ) | 1.8 | 100*85*250 | 0200 |
| 0250 | 1 1/2 " (1" ) | 3.6 | 140*115*325 | 0250 |
| 0300 | 1 1/2 " (1" ) | 6.6 | 140*115*420 | 0300 |
| 0350 | 2" | 9.6 | 180*155*550 | 0350 |
| 0400 | 2 1/2 " | 14.6 | 180*155*550 | 0400 |
| 0450 | 2 1/2 " | 20 | 180*155*750 | 0450 |
| 0500 | 2 1/2 " | 25 | 180*155*750 | 0500 |
| Model | Connection | Air Flow Rate | Dimensions | Filter Element Model |
| Hankinson | mm | Nm³/min | mm | |
| 001 | 1" | 1 | 90*80*200 | -16 |
| 002 | 1" | 2 | 90*80*270 | -20 |
| 003 | 1 1/2 " | 3 | 130*115*320 | -24 |
| 006 | 1 1/2 " | 6 | 130*115*480 | -32 |
| 013 | 2" | 13 | 130*115*590 | -36 |
| Model | Connection | Air Flow Rate | Dimensions | Filter Element Model |
| High Pressure 30 bar | mm | Nm³/min | mm | |
| 015 | 1" | 1.5 | 80*80*220 | -16 |
| 024 | 1" | 2.4 | 80*80*260 | -20 |
| 035 | 1" | 3.5 | 90*90*270 | -24 |
| 060 | 1 1/2 " | 6 | 117*117*460 | -28 |
| 090 | 2" | 10 | 140*140*590 | -36 |
Guangdong Jufeng Manchinery Manufacturing Co., Ltd. is a professional air compressor manufacturer, dedicated to air compressor researching, developing, and manufacturing. We have our very own factory. It is equipped with 12 advanced production lines, with a production output of about 40000 (of kinds of products) per year. At Jufeng, we stand for industry-leading quality in air compressors. In nearly every industry driven by compressed air technology, our reputation speaks for itself. You will find Jufeng air compressors raising the bar for performance and emerging as a leader in the industry. Designed to deliver reliable, stable pressure, low operating and maintenance costs, and ongoing energy savings, Jufeng products are a great choice for any growing business.
